How to install the best LEDs on the low beam and high beam headlights of your Renault Clio 4?

💡 Where to buy your LEDs for Clio 4?

To simplify your purchase and replace all of your original bulbs with LEDs, go here: 👉 /en/search-led-accessories/renault/clio-4/1028892

🎥 Want to see more in video?

Discover all the LED installation videos on Renault Clio 4 on the TikTok channel: @alm_1501.

We approve of his technical expertise and his advice!

👇 In this blog, we detail step by step the installation and the choice of the best LEDs for those who want to understand everything in detail.

🔌 Low beam headlights: installation and precautions

1. Preparation before installation

• Identify the height of the original light beam with halogen bulbs, ideally at night or in the dark, so you can compare after installing the LEDs.
• Only do this step if you are sure your headlights are already properly adjusted. Otherwise, plan a visit to the mechanic after installation for a professional adjustment.

2. Removing the original H7 halogen bulbs

• Remove the two cover caps: one on the grille side, the other on the engine side.
• Disconnect the connector, making rocking movements if necessary.
• Press on the retaining clip while shifting it slightly to release the bulb.

Two types of LEDs are possible:

• High-performance LEDs with rear ventilation, for maximum power.
• GTS 1.1 compact LEDs, easier to install, with a precise light beam and brightness 450 % higher than the original: AGM Vision GTS 1.1 Slim

⚠️ Very powerful models must be chosen carefully to avoid glare.

👉 Recommended model for Clio 4, our LED pack: /en/product/pack-led-veilleuse-avant-renault-clio-4-de-2012-a-2020-2942 or the ultimate ones: /en/product/kit-ampoules-led-h7-millenium-2-1152

3. Installation depending on the type of LED

H7 LED with rear ventilation for low beams:

• Remove the metal ring from the LED (quarter turn).
• Install it in the headlight housing (place a cloth in case of accidental drop).
• Orient the keying tab upward.
• Insert the LED into the ring, then lock with a quarter turn.
• Orient the cable upward or downward (never at an angle).
• Connect the connector. If the LED does not light up, reverse the connection (polarity).

GTS 1.1 compact H7 LEDs for low beams:

• Install the LED directly, like an original bulb.
• Clip the retaining clip.
• Connect the connector (no specific direction).
• Put the two cover caps back on for sealing.

4. Beam adjustment

• Test the lighting at night. If the beam is too high, adjust the position of the LED or use the adjustment wheel in the cabin.
• For an optimal result, have it adjusted in a garage with a headlight aiming device.

🔍 Common issue: connecting H1 LEDs on Clio 4

Some users have difficulty connecting their H1 LEDs. Don’t panic: we explain how to do it, and above all how to choose your LEDs properly.

💡 Key tip: choose 360° LEDs

For high beams, it is essential to choose powerful LEDs, with a 360° beam, with precise focus. This guarantees efficient lighting without modifying the headlight optics.

👉 Recommendation:

Pack LED High beams Clio 4 (2 covers included + H1 LED 360° bulb kit)

⚠️ Why avoid standard LEDs?

• The H1 bulb is positioned laterally in the headlight unit.
• A standard LED does not orient the light correctly.
• Result: incomplete beam, reduced range, non-uniform lighting.

✅ With a well-designed LED, you get a powerful, well-distributed light that complies with road regulations, without tinkering or modification.

1. Removing the original H1 halogen bulbs

• Remove the headlight cover, located next to the car’s fender.
• Remove the connector and the clip (press/shift, then lift).
• Remove the original bulb.

2. Installing H1 LEDs for the high beam

• Remove the metal ring from the LED by pulling upward.
• Install the previously removed metal ring in the headlight (use a cloth to prevent it from falling).
• Reattach the clip to hold the ring.
• Do not put the LED back into the ring right away: first do the wiring.

3. Clio 4-specific wiring

How to correctly connect the LED ground?

LED bulbs have two wires (positive and ground), but the Clio 4 has only one visible connector, which can be confusing. Most often, the ground wire (–) is hard to identify because it is hidden in the headlight housing.

• 🔌 Black wire (–) of the LED: connect it to the female connector located at the bottom of the headlight housing (note: the wire is sometimes white or brown). Use a flathead screwdriver to pull it out. It is located about 1 cm around the original location of the H1 bulb.
• 🔴 Red wire (+) of the LED: connect it to the original female socket, the one used by the H1 halogen bulb.

👉 Once both wires are connected, you can insert the LED into its housing.

4. Waterproof cover to plan for

• The original cover often no longer closes after installing LEDs for high beams. No problem: AGM Vision provides deeper covers (included in this pack Pack LED High beams Clio 4) with the same diameter as the original, to ensure sealing.

💡 LED pack and LED bulbs recommended for Clio 4

• Pack LED High beams Clio 4 : 360° beam, uniform light and long range.
• H7 GTS 1.1 Slim LED kit (low beams) : excellent compromise between power, visual comfort and ease of installation.
• Pack LED Low beams Clio 4 : high power, reliable for sensitive optics.

❌ Mistakes to avoid

• Installing LEDs without adjusting the headlights: risk of dazzling other drivers.
• Reversed polarity: if the LED does not light up, reverse the connection.
• Incorrect orientation: poorly directed beam = reduced visibility.
• No waterproof cover: moisture can cause failures.
• Wrong choice of LEDs for high beams.
